Product Description

The TN650 LRF 2.0 is a thermal binocular with a built-in laser rangefinder, designed for thermal image viewing in outdoor and low-light environments. It features a 640×512 @ 12μm infrared detector, 50mm F1.0 objective lens, and a 0.49" AMOLED 1920×1080 display for clear image viewing.

This model includes a 1630 yd laser rangefinder, photo and video recording with audio, dual-band Wi-Fi, USB-C charging support, 128GB memory, and a dual battery system with one built-in battery and one external 18650 battery.

KEY FEATURE

  • 640×512 @ 12μm sensor resolution
  • 18mK NETD thermal sensitivity
  • 50Hz sensor frame rate
  • 50mm, F1.0 objective lens
  • 8.2° × 5.0° field of view
  • 3.9x–31.2x magnification
  • 2800 yd detection range
  • 1630 yd laser rangefinder
  • Manual focus
  • 0.49" AMOLED 1920×1080 display
  • White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, and Sepia color palettes
  • USB-C interface with charging support
  • Wi-Fi 2.4G and 5G
  • Microphone, compass, gyroscope, and Bluetooth
  • Photo and video recording with audio
  • 128GB memory capacity
  • Built-in battery and external 18650 battery
  • Up to 7 hours operating time
  • IP67 protection rating

PRODUCT DETAILS

Product Name: TN650 LRF 2.0 Thermal Binoculars 3.9x 640x512 50mm Laser Rangefinder
Brand: Guide Thermal USA
Vendor: Guide USA
Product Type: Thermal Binoculars
Dimensions: 8.2" × 5.39" × 2.69"
Use: Thermal image viewing for outdoor and low-light observation

Description
Sensor
Type Uncooled VOx Infrared Detector, 8 to 14μm
Resolution 640×512@12μm
NETD 18mK
Frame rate 50Hz
Lens
Objective lens 50mm, F1.0
Field of view 8.2°×5.0°
FOV m@100m 14×9
Magnification 3.9x~31.2x
Detection range 2800yd
Focus Manual
Display
Display type 0.49" AMOLED 1920×1080
Color palettes White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
Eyepiece Eye relief: 20mm; Diopter: -6 to +6; Interpupillary distance adjustment: 58-72mm; Zoom: 13.8x
Hardware
Laser rangefinder 1630yd
WIFI 2.4G, 5G
Interface USB-C (Support charging)
Others Microphone, Compass, Gyroscope, Bluetooth
System
Recording function Photo/Video (Audio recording included)
Memory capacity 128GB
Power
Battery type Customized Battery (Built-in) and 18650 ×1 Battery (External)
Operating time 7 hours
Environmental
Operating temp. -4°F to +122°F
Encapsulation IP67
Physical
Weight
(oz)
25.11
Size (in) 8.2×5.39×2.69
Standard Device, Eye Mask, Neck Strap, Carry Bag, 18650 Battery ×1, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card
Optional Bluetooth Remote Control, 18650 Battery
Feature Image 1
Feature Image 2
Feature Image 3
Feature Image 4
